081 Vehicle Connector——Weichai WP7 SERIES DIESEL PARTS CATALOGUE
Pos. Teile.Number Amount Designation
1 612640080023 1 Connector
2 612640080028 1 Plug Whatsapp: 86-18630852087
3 612640080029 14 Plug
4 612640080049 6 Sealer
5 612640080024 6
6 612640080047 1 Secondary Lock
7 612640080027 81
8 612640080025 3
9 612640080046 1 Secondary Lock Whatsapp: 86-18630852087
10 612640080045 1 Socket connector case
11 612640080048 1 Clip
12 612640130156 3 Nitrogen-Oxygen Sensor Connector Sealer（967067-1）
082 Electronic Control Unit Group——Weichai WP7 SERIES DIESEL PARTS CATALOGUE
Pos. Teile.Number Amount Designation
1 612640080460 1 Electronic Control Unit Whatsapp: 86-18630852087
2 612639000050 4 Hexagon Head Bolt
083 Electronic Control System Harness Group——Weichai WP7 SERIES DIESEL PARTS CATALOGUE
Pos. Teile.Number Amount Designation
1 610800081345 1 Engine Harness Set
2 90013050025 4 Inner Hexagon Socket Head Cap Screw
3 90003932008 6 Wave Spring Washer
4 610800081204 3 Harness Bracket
5 610800080363 2 Harness Bracket
6 90003932023 2 Wave Spring Washer
7 90003802402 2 Hexagon Head Bolt Whatsapp: 86-18630852087
8 90003802312 1 Hexagon Head Bolt
9 610800080364 1 Harness Bracket
10 612630030007 2 Speed Sensor
11 610800080165 1 Harness Bracket
12 90013050025S 1 Inner Hexagon Socket Head Cap Screw
13 610800080166 1 Harness Bracket
14 610800080168 2 Harness Bracket
15 612600080275 1 Sealing Washer
16 90003962030 1 Hexagon plug Whatsapp: 86-18630852087
17 90011400013 2 Hexagon Flange Bolt
18 612600090460 1 Pressure and Temperature Sensor
084 Alternator Group——Weichai WP7 SERIES DIESEL PARTS CATALOGUE
Pos. Teile.Number Amount Designation
1 610800090078 1 Ferrule 24° Cone Connectors,Nut
2 610800060626 1 Bracket Whatsapp: 86-18630852087
3 1000480368 1 Alternator
4 90011430017 3 Hexagon Flange with Tooth Bolt
5 90003802493 1 Hexagon Head Bolt
6 90003932024 1 Wave Spring Washer Whatsapp: 86-18630852087
7 90011420005 1 Hexagon Flange Bolt
8 90011430018 1 Hexagon Flange with Tooth Bolt
9 610800060627 1 Bracket
