AYB85 Hydraulic Transmission
Product Introduction
AYB85 hydraulic transmission is a fixed shaft multi-gear hydraulic transmission, double variable one, through electro-hydraulic proportional control, can achieve four front and four reverse gears, can automatically shift.
Main Technical Parameters
● Maximum Engine Power: 82 kW
● Maximum RPM: 2200 rpm
● Maximum Torque: 750Nm
● Gears: 4 forward and 4 reverse
● Gear Ratio: 4.426/2.687/1.226/0.649 (same for both forward and reverse gears)
● Zero Speed Torque Ratio: 2.64
● Shifting method: Electro-hydraulic proportional control
● Input type: Direct connection between torque converter and flywheel housing
● Output type: Flange-mounted dual outputs
● Input/Output Center Distance: 350mm (front/rear outputs aligned on the same axis)
Product Application
The AYB85 hydraulic transmission is used in excavators and loaders (dual-function models) and similar industrial machinery requiring equivalent operational performance.
