EH100/EH120 Drive Assembly
Product Introduction
The EH100/EH120 drive assembly integrates the walking powertrain and hydraulic powertrain into a single unit, achieving optimization between vehicle components through the rational layout of the motor, electronic control, and gearbox. The drive assembly adopts a horizontal layout design with dual motors for power and hydraulics. The powertrain delivers the vehicle's walking power output via front and rear output flanges, while the hydraulic assembly meets the hydraulic power take-off requirements through output splines.
Main Technical Parameters
● Maximum speed of travel motor: 12000 rpm
● Maximum speed of hydraulic motor: 6800 rpm
● Maximum output torque: 3900 N.m
● Gears: Two-speed (single-speed optional)
● Shifting method: Hydraulic sleeve shifting (two-speed)
● Output form: Front and rear output flanges
Product Application
Applicable to products for 1.5-ton to 3-ton loaders or similar working conditions.
