YB82 HYDRAULIC TRANSMISSION
Product Introduction
The YB82 hydraulic transmission is a fixed shaft multi-speed hydraulic transmission with dual variations, controlled by electro-hydraulic control and fork structure, achieving four forward and four reverse gear functions.
Main Technical Parameters
● Maximum engine power: 82kW
● Maximum engine speed: 2200r/min
● Maximum input torque: 680N.m
● Gears: Four forward and four reverse, n rear axle/n front axle = 0.8 (high-speed, front axle speed is higher)
● Shifting method: Direction is controlled by electro-hydraulic control, gear is controlled by fork and synchronizer shifting
● Input type: The torque converter is directly connected to the flywheel housing
● Output type: Flange, dual output, input and rear axle output (input on the opposite side) center distance: 180mm; input and front axle output (input on the same side) center distance: 332.5mm
● Maximum torque for take-off: 280N.m
Product Application
The YB82 transmission is used in excavating loaders (Backhoe Loader) and similar products with similar working conditions.
