YDH85 Hydraulic Transmission
Product Introduction
YDH85 hydraulic transmission is a fixed shaft multi-gear hydraulic transmission, which integrated the converter and gearbox, through the combination of proportional valve and switch valve control, can achieve four front three reverse gears, can automatically shift.
Main Technical Parameters
● Maximum engine power: 85 kW
● Maximum engine speed: 2500 rpm
● Maximum input torque: 650N.m
● Gears: 4 forward and 3 reverse
● Shifting method: Combined proportional valve and switch valve control
● Input/output center distance: 648mm horizontally, 227mm vertically
● Input type: Torque converter directly connected to flywheel housing
● Output type: Flange, dual outputs
Product Application
YDH85 hydraulic transmission is suitable for reach truck applications and similar equipment requiring similar operational conditions.
